1.1KW Inline V Cut X Y Axis PCB Separating Equipment 0.6mm Blade

1.1KW Inline V Cut X Y Axis PCB Separating Equipment 0.6mm Blade
1.1KW Inline V Cut X Y Axis PCB Separating Equipment 0.6mm Blade

Large Image :  1.1KW Inline V Cut X Y Axis PCB Separating Equipment 0.6mm Blade

Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE,RoHS
Model Number: HS-F550
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case with foam protective
Delivery Time: 1 month
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100pcs per month
Detailed Product Description
Product Name: Inline V-cut PCB Separating Max Separating Length: 1-500mm
Circular Blade Size: Φ125*30*3mm Linear Blade Size: 420*45*6mm
Cutting Thickness: High Speed Steel Cutting Tool Application: Tic Tac Toe Connected PCB Panel
Warranty: 1 Year
High Light:

Y Axis PCB Separating Equipment

,

1.1KW PCB Separating Equipment

,

0.6mm Blade PCB Depaneling Equipment

Inline V-cut X Y axis Automatic PCB Separating Depaneling Equipment



Description


This PCB separating machine is a full automatic inline V-cut type PCB separating machine, it's use the PCB loader to achieve automatic PCB loading, and the belt will trasport the PCBs for X axis and Y axis automatic Separating with linear blade and circular blade combined.

Operator just put the boards into the magazines and wait the PCB units after separating at the end of the machine.It's a high automatic PCB separating machine.



Features


1, Automatic inline separating.

2, Automatic feeding with PCB loader, automatic X axis and Y axis  direction vcut separating.

3, With waste PCB collecting box.

4, Transporting belt for collecting after separated.

5, PLC control precision PCB depaneling, can connect the PCB loader machine, full automatic from board loading and collecting.

6, Save the labour for manual loading the PCBs, much efficiency and more precision.

7, Can save 100 groups board separating data, when separating different type boards, just import the saved data, very convenient.

8, Moving balde type boards separating method, ultra low cutting force stress, suitable for PCB with components double sided.
9, The machine equipped with infrared light curtain sensor, high security.

10, Taiwan brand TBI lead screw, smooth and easy adjusted.
11, High speed Japan brand steel balde, can be sharpen repeatly.
12, The machine can add the SMEMA single, can connect the PCB loader to achieve automatic loading.



Specification



Model HS-F550
Efficiency cutting length 0-500mm
Separating width ≤ 300mm
Circular blade size Φ125*30*3mm
Linear blade size 420*45*6mm
Blade thickness 0.3-0.6mm
Separating speed Adjustable
Separating thickness ≤2mm
Blade material Overseas high quality steel blade
Production ability 100,000pcs per day
Voltage AC110V/220V
Air pressure 0.5-0.8Mpa
Power 1.1KW
Machine dimension 1500*550*1550mm
Weight 325KG



Application panels
