Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator

Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator

  • Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator
  • Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator
Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator
Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE
Model Number: HS-310
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package
Delivery Time: 7~9 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Guillotine PCB Separator Warranty: 1 Year
Control: Touch Screen PLC: MITSUBISHI
Relay Brand: Schneider Optoelectronic Switch: OMRON
Material: Aluminum Alloy Condition: New
Thickness: 0.3 - 5mm Signal: SMEMA
Application: Electronic Assembly Color: Silver
Control System: PLC OEM/ODM: Available
Total Power: 2600W Power Supply: AC220V
Air Pressure: 4-6bar Mounting Accuracy: ±0.01mm
Type: Automatic Weight: 30KG



Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator



​Specification

Model HS-310
Voltage 110V/220V(optional)
Power 10W
Air pressure 0.5~0.8Mpa
Efficient cutting length 1-360mm
Linear blade size 360*43.5*6mm
Blade material Import high quality high speed steel tool
Separating speed 1-300mm/s
V-cut thickness 1/3 of the board
Air consumption 200-400(L/min)
Machine size 700*325*400mm
Weight 130kg





Features

1, Guillotine type separating,low force stress 700-800uE,high quality cutting.

2, Suitable for all kinds of material board,also can cutting high hardness,aluminum,and cooper board.

3, Security: small guillotine only available for board feeding,ensure the safety of the operator.

4, Very easy to learn and operating.

5, Durable, using import high quality steel made cutting tool.

Application

This machine is pneumatically driven and electric control, built in 6 digits counter which is convenient for counting the cuts.The linear knife type depaneling machines were designed to depanel prescored panelboards carefully, without bending or tension stress.

Even sensitive SMD-components like ceramic capacitors will not be damaged by the depaneling process. It suitable for all kinds of pcb board, LED aluminum board,COB board, cooper board,etc. It’s widely used, low cutting force stress, few cutting burrs,and the board side is smooth and flat, it’s a best choice for high quality board cutting.



About Packaging

Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator 0

Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator 1

Durable Guillotine Type Separating Cutting High Hardness Pneumatic Guillotine PCB Separator 2
