CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine

CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine

  • CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine
  • CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine
CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine
Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE
Model Number: HS-RM-560
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package
Delivery Time: 7~9 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Product Name: PCBA Router Machine Warranty: 1 Year
Control: Touch Screen Relay Brand: Schneider
Optoelectronic Switch: OMRON Material: Aluminum Alloy
Condition: New Signal: SMEMA
Application: Electronic Assembly Color: Silver
Control System: PLC OEM/ODM: Available
Power Consumption: 200W Type: Automatic



CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine



Machine introduction



This automatic PCB router machine using high speed-routing spindle, equipped with double platform, 4 axis servo motor driven,

the spindle moving according to the preset programming, automatic separating the stamp hole connectted board, curve board,and other inregular shape boards.



The machine use window operation system, CCD detection the separating track,can check the separating process any time.



Features



1, High speed routing spindle, 6000rpm.


2, Windows operation, manual location or file import.


3, CCD detection.


4, Internal dust-collector including.



5, Suitable for separating FPC board, aluminum board, FR4,etc.



6, Mainly used for separating stamp hole connected board, curve board, instead of traditional v-cut board.



Specification
Model RM-560
Structure Single Spindle,dual work platforms
Machine Size(mm) 1000*1200*1550
Gross Weight 700kg
Dust collector size(mm) 625*600*1600
Dust Collection method Bottom collection
Work platform size 300*400mm
Platform driving type Double rotary platform,precision slicer with 3phase motor inverter
Driving system X/Y/Z axis driven by servo motor,W axis driven by three phase motor frequency inverter
Routing Spindle 6000rpm
Cutting speed 1-100mm/s
Cutting accuracy ±0.05mm
Repeat accuracy ±0.02mm
Axis moving speed 800mm/s
Z axis system Screw driven,dual guide
Router kit milling cutter,φ0.8~φ3.0 left rotation,Shank Tungsten Steel
Tool life control Software program control
Active protective function safty light curtain
Security door Manual door
Error alarm Yes
Program method Self programing,camera controlled by keyboard and mouser



Machine details


High Speed routing spindle and internal dust-collector



Fixture Customized Visual Check Automatic PCB Router FPC Aluminum Board FR4 Curve 0

Windows7/10 English version operating system,simple for debugging and operation.


Fixture Customized Visual Check Automatic PCB Router FPC Aluminum Board FR4 Curve 1



Fixture Customized Visual Check Automatic PCB Router FPC Aluminum Board FR4 Curve 2





About Packaging
CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine 3
CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine 4
CCD Detection High Speed Routing Spindle Internal Dust-Collector Including PCBA Router Machine 5
