YAMAHA CL 8x2mm SMT Feeder for YV/YG Series Chip Mounting Machine

YAMAHA CL 8x2mm SMT Feeder 8mm Width for 0402 Components KW1-M1300-00X

Introduction

This Yamaha CL 8x2mm,8x4mm series feeder are used for YV/YG series chip mounting machine, it suitable for pick and place components like

 0402,0603,1206,0805,3014,3528,4148,SOT23,etc SMD components and LED chips.

Specification

YAMAHA inductor fault generation and analysis

We found that the Mount Head picks up components with a certain deviation, and the suction nozzle is very difficult to pick up the component right in the centre, which will cause some impact on the placement. However, this is not the case if the machine is changed to direct pickup, i.e. the Mount Head picks up components directly from the pallet without passing through the feeding platform. From this we analyse that the position of the Mount Head and the Tray Head on the feeder table is not on the same axis as the placement of the component, resulting in pick-up errors.

YAMAHA Feeder Part Number

YAMAHA CL 8*2mm Feeders for 0201 KW1-M1500-030
YAMAHA CL 8*2mm Feeders for 0402 KW1-M1300-00X
YAMAHA CL 8*4mm Feeders KW1-M1100-000
YAMAHA CL 12mm Feeders KW1-M2200-100
YAMAHA CL 16mm Feeders KW1-M3200-100
YAMAHA CL 24mm Feeders KW1-M4500-014
YAMAHA CL 32mm Feeders KW1-M5500-000
YAMAHA CL 44mm Feeders KW1-M6500-000
YAMAHA CL 56mm Feeders KW1-M7500-000
YAMAHA CL 72mm Feeders KW1-M8500-000
YAMAHA FEEDER FSII8*2MM KJK-M1500-000
YAMAHA FEEDER FSII8*4MM KJK-M1500-011
YAMAHA FEEDER FT8*2MM KJK-M1500-010
YAMAHA FEEDER FT8*4 MM KJW-M1200-023
YAMAHA FEEDER FS2 8*4MM KJK-M1500-013
YAMAHA FEEDER SS 8MM KHJ-MC100-000
YAMAHA FEEDER SS12 MM KHJ-MC200-000
YAMAHA FEEDER SS16 MM KHJ-MC300-000
YAMAHA FEEDER SS 24MM KHJ-MC400-000
YAMAHA FEEDER SS32MM KHJ-MC500-001

YAMAHA FEEDER SS44MM KHJ-MC600-000

YAMAHA FEEDER SS56MM KHJ-MC700-000

YAMAHA FEEDER SS72MM KHJ-MC800-000
