High Inspection Rate CCD Inline THT DIP AOI Automatic Soldering Robot With 4-6bar Air Pressure and Convolutional Neural Network Algorithm

Brand Name:	HSTECH
Model Number:	AIS300
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T,Western Union
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Inline THT DIP AOI After Wave Soldering

Warranty:

1 Year

Control:

Touch Screen

PLC:

MITSUBISHI

Relay Brand:

Schneider

Optoelectronic Switch:

OMRON

Material:

Aluminum Alloy

Signal:

SMEMA

Control System:

PLC

OEM/ODM:

Available

Packaging Details:

Wooden package

Supply Ability:

50 sets per month

Highlight:

High Inspection Rate CCD Inline THT DIP AOI

4-6bar Air Pressure Automatic Soldering Robot

Convolutional Neural Network Algorithm Wave Soldering Machine

Product Description

High Inspection Rate CCD Inline THT DIP AOI After Wave Soldering With 4-6bar

Advanced automated optical inspection system designed for through-hole technology (THT) and dual in-line package (DIP) components after wave soldering processes. Features high-precision CCD imaging and 4-6 bar air pressure capability for superior defect detection.

Technical Specifications

Model	AIS300	AIS301
PCB Size	50x50mm~430x380mm	50x50mm~350x350mm
Thickness	0.3~7.0mm
Warping extent	<4mm
Component height	Top 150mm, bottom 25mm
Camera	5MP, color, CCD
Light source	RGB
FOV	45*37mm
Resolution	20um
Speed	0.23sec/fov	0.25sec/fov
Operation system	Ubuntu 14.04 LTD 64bit
Industrial PC	CPU intel i5, Independent Graphics Card, 12G DDR, 256SSD
Display	22 inch FHD LCD
Motion	High accuracy linear actuator
Power supply	AC220V, 1KW
Air pressure	>0.5Mpa
Dimension (LHW)	110016301350mm	110012801300mm
Net Weight	800kg	700kg

Inspection Capabilities

Mounting Components Defect Detection

Missing components
Rolling components
Component offset
Component damage
Component skew
Redundant components
Dirty components

Solder Defect Detection

Excess solder
Insufficient solder
Solder bridges
No foot solder
Missing solder
Non-wetting

Additional Functions

Bar-code reading
QR code scanning
Optical character recognition (OCR)

Key Features

Advanced Core Algorithm: Convolutional Neural Network Algorithm with human-like inspection capabilities
Superior Compatibility: Training algorithm model of super large sample set with high generalization
Enhanced Detection: Super detection ability with lower false positive rates
User Training Support: Supports user self-training models
High Wear Resistance: Durable construction for industrial environments
Large Inspection Area: High compatibility with various PCB sizes
High Inspection Rate: Optimized for efficiency with low false positive rates
Stable Platform: Marble base for enhanced stability
Precision Motion: Dual XY linear actuators for high speed and accuracy

Applications

This inline THT AOI system is specifically designed for use after wave soldering machines in DIP production lines. It effectively corrects defective units, reducing repair requirements and downtime while significantly improving production passing rates. Widely used for inspecting TV mainboards, PC mainboards, power boards, industrial control boards, mini household electronic appliances, and various other PCB assemblies.
