Splitting machine, LED splitting machine, milling cutter type splitting machine 1. Electric hybrid design, milling cutter slitting, especially suitable for splitting precision SMD thin plates, aluminum circuit boards 2. Guillotine type work, suitable for PCBs of various thicknesses. The cutting stroke is less than 2mm, so there are no concerns about operational safety. 3. Reduce the internal stress generated during cutting to less than 180μST to avoid tin cracks and prevent damage to precision parts. 4. The edge of the V-groove and the parts can be cut The maximum width is 0.3mm and the height is 60mm5. The tool can be sharpened repeatedly after wear.

Board splitting machines are generally divided into V-groove board splitting machines and non-V-groove board splitting machines.

1. The most common V-groove depaneling machine is the knife-type depaneling machine. The characteristics are as follows:
1. During the cutting process, the PCB does not move and the circular knife slides to ensure that the electronic components of the substrate are not damaged due to movement.
2. The sliding speed of the circular knife is adjustable.
3. In response to the depth of the V-groove and tool wear, the distance between the upper circular knife and the lower straight knife can be accurately adjusted.
4. It can solve the problem of parts crossing the V-groove to realize splitting.
5. Minimize the internal stress generated during board cutting to avoid tin cracks.
6. The cutting speed is controlled by the knob, and the splitting stroke can be freely set and has an LCD display.
7. Conveyor belts can be installed as required to improve performance.
8. Three sets of electric eye protection to ensure safe production.

Features

☆The entire machine is designed using the C-shaped structural principle of no bending stress and high rigidity.
☆Use compressed air as power to process V-cut connecting and splitting operations.
☆Safely separate boards for extremely sensitive SMD parts or ultra-thin PCBs.
☆No vibration occurs during panel splitting operation.
☆Pneumatic drive, quiet and noiseless.
☆The upper and lower tool gaps can be easily adjusted.
☆The lower knife can be adjusted in YZ direction.
☆The tool is designed with a face angle structure and can cut PCB parts that are almost close to the V-groove.
