Introduce

The pick-and-place nozzle is an important component in the placement machine. It is used to pick up and position surface mount components (SMT Components) and place them accurately on the printed circuit board (PCB). superior. The suction nozzle is a key part of the placement machine, which directly affects the accuracy and efficiency of the placement process.

The following are some characteristics and working principles of the placement machine nozzle:

1.Picking up components: The suction nozzle picks up surface mount components through the principle of negative pressure (vacuum). It usually has an adjustable nozzle diameter and shape to accommodate different types and sizes of components.

2.Material and coating: Nozzles are usually made of wear-resistant and corrosion-resistant materials, such as stainless steel or ceramics, to ensure long-term stable operation. Some nozzles are also specially coated to provide better adsorption and anti-stick properties.

3.Adaptability and replacement: SMT nozzles often have a replaceable design to easily accommodate different sizes and types of components. By changing the nozzle, it can adapt to different component packaging, such as chips, QFP, BGA, etc.

4.Positioning accuracy: After sucking the component, the nozzle can accurately locate the position and direction of the component. This is important to ensure components are placed exactly where they are intended on the PCB to ensure soldering quality and reliability.

5.Nozzle cleaning: Since the nozzles come into contact with components and patch glue during work, they may become contaminated and adhere. Therefore, regular cleaning of the nozzle is necessary to ensure its adsorption power and stability.

Nozzle classification: high-speed head and general-purpose head

1. The high-speed head is mainly used to pick up relatively small components: such as 0201,0402

2. The general-purpose head mainly absorbs relatively large components or some heterogeneous components. The mounting speed of the general-purpose head is generally slow.

Nozzle shape

The shape of the suction nozzle includes square hole, round hole, and V groove.

SMT (Surface Mount Technology) nozzle is an important tool used in automated placement equipment for electronic components, used to pick up and place small electronic components. There are many types of SMT nozzles according to different needs, common ones include:
