Automatic 5 Axis Dual Table Robotic Soldering Machine Programmable Teach Pendant For PCB Assembly

Name: Automatic 5 Axis Dual Table Robotic Soldering Machine Programmable Teach Pendant For PCB Assembly
Brand: Shenzhen Hansome Technology Co., Ltd.
SKU: HS-S5331R
Price: 3,450.00 USD
Availability: InStock

Brand Name:	HSTECH
Model Number:	HS-S5331R
MOQ:	1 PC
Price:	negotiation
Payment Terms:	T/T
Supply Ability:	50 PC/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ISO

Product Name:

Tabletop Soldering Robot

Soldering Head:

Single Tip

Rotation:

360degree

System:

Manual Programming, Fast Swtiching

Machine Weight:

90KG

Warranty:

1 Year

Packaging Details:

Wooden

Supply Ability:

50 PC/Month

Highlight:

5 axis robotic soldering machine

programmable PCB assembly robot

dual table automatic soldering robot

Product Description

Automatic 5 Axis Dual Table Robotic Soldering Machine

The HS-S5331R 5 Axis Dual Table Robotic Soldering Machine is an intelligent automated soldering solution designed for precision electronic assembly. Equipped with dual working stations and a 5-axis motion system, this robotic soldering platform delivers stable, consistent high-quality soldering for PCBA, connectors, wire terminals and miniature electronic components.

Core Features

5-Axis Motion Soldering System: Multi-dimensional movement with 360° rotary R axis enables flexible soldering at complex angles and handles irregular soldering positions efficiently
Stepper Motor Drive Control: Stepper motor + timing belt transmission system provides stable operation, low vibration and outstanding positioning consistency for long-hour continuous production
Precise Temperature & Broken Tin Control: Real-time temperature monitoring with accurate broken tin control prevents excess solder, cold solder joints, bridging and tin beads
High-Grade Linear Guide Rail: Premium linear guide structure ensures ultra-smooth, flat movement, minimizes motion deviation and extends machine service life
Multiple Soldering Modes: Supports spot soldering (point soldering) and drag soldering, customizable to match diverse workpiece soldering requirements
High-Strength Aluminum Alloy Machine Arm: Custom alloy cantilever structure is anti-rust, anti-deformation, maintaining structural stability under long-term continuous operation
Teach Pendant Programming: User-friendly handheld teach box for easy path programming with storage for up to 99 groups of independent soldering programs
Built-in Smoke Purification Filter System: Effectively filters harmful fume generated during soldering, protects soldering iron tip from corrosion and improves workshop environment

Technical Specifications

Model	HS-S5331R
X/Y1/Y2/Z Working Range	500×300×300×100 mm
R Axis Rotation	360°
XYZ Max Moving Speed	300 mm/s
Drive System	Stepping Motor + Timing Belt
Repeat Positioning Accuracy	±0.02 mm
Operation Mode	Fully Automatic
Programming Method	Manual Programming via Teach Pendant
Control System	Constant Temperature Control System
Control Unit	Control Board
Machine Weight	90 kg
Overall Dimension (L×W×H)	716×585×800 mm
Power Supply	220V, 50–60Hz
Temperature Control Range	0–550°C
Soldering Tip Cleaning Method	Air Pneumatic Cleaning
External Communication Interface	USB + RS232
Soldering Methods	Point Soldering / Drag Soldering
Working Environment Temp & Humidity	5–40°C, 20%–90% RH (Non-condensing)

Application Scenarios

Suitable for automated soldering processing of PCB circuit boards, FPC flexible boards, electronic connectors, wire harness terminals, sensors, small modules, audio components, consumer electronics, medical electronics, and automotive electronic assemblies.

Product Advantages

Dual-table Alternating Work Design: Two workstations work alternately, saving loading/unloading waiting time and boosting production efficiency
Ultra-high Soldering Consistency: Replaces manual soldering, eliminates unstable quality caused by human operation, and reduces defective rate
Simple Operation & Low Learning Cost: Intuitive teach pendant programming allows operators to complete program editing quickly without professional programming knowledge
Environment-friendly Design: Integrated smoke purification system removes soldering fume and meets factory environmental standards
Long Service Life & Low Maintenance Cost: Rust-proof alloy frame and reliable transmission components support long-time non-stop industrial production
