Guillotine Type PCB Separator Pneumatic Power PCB Separator With 2 Linear Blades

Pneumatic Power PCB Panel Separator For SMT Assembly Line V Cut PCB Singulation Equipment Precision Depaneling Machine

Product Introduction

The Pneumatic Guillotine PCB Separator is a professional pneumatic driven PCB depaneling machine designed for precision separation of V cut PCB panels in SMT production lines. Equipped with 2 linear guillotine type blades, this pneumatic PCB separator adopts guillotine shear cutting principle to complete one time accurate singulation of connected circuit boards. Different from traditional manual breaking and rolling cutting methods, this guillotine type PCB separator delivers stable and flat cutting results, effectively solving common industry problems such as solder joint cracking, micro cracks, component damage and uneven incision. Fully powered by pneumatic system without electric drive interference, the PCB panel separator features simple operation, stable running and wide compatibility, covering separation demands of standard PCB boards, aluminum substrates, copper substrates and various thin SMD circuit boards, serving as essential precision equipment for modern electronic manufacturing production.

Function:
Cutting and separating the segmentation line reserved by the PCB can be accurately.
Support PCB boards of various sizes and shapes for separation operations.
It has fully automated functions such as automatic feeding, positioning, cutting, and materials.
During the cutting process, the edge of PCB can be kept intact to avoid damaging components.
Can cooperate with other equipment in the production line to achieve continuous automation.

Main feature:
The cutting force driven by an electric push rod or hydraulic pressure is large and stable.
Equipped with a high -precision optical positioning system to ensure that the cutting line is accurate.
There is an automatic feeding and dispenser to reduce the burden of manual operation.
There are multiple cutting modes, such as a single and multiple PCB separation at the same time.
The device structure is compact, the area is small, and it is easy to integrate to the production line.
With safety protection devices, such as emergency stops, grating, etc.

Main component:
Blade mechanism: Including blade, driving motor/hydraulic system.
Optical positioning system: uses cameras, image processing algorithms, etc.
Entry and exit institutions: Automated equipment such as conveyor belts, robots.
Program control system: PLC or embedded controller to achieve fully automation.
Safety protection device: such as emergency stop switch, grating sensor, etc.

Features

1, Guillotine type separating,low force stress500-600uE,high quality cutting.
2, Suitable for all kinds of material board,also can cutting high hardness,aluminum,and cooper board.
3, Security: small guillotine only available for board feeding,ensure the safety of the operator.
4, Very easy to learn and operating.
5, Durable, using import high quality steel made cutting tool.

Specification

Application Scenarios

This Pneumatic Guillotine PCB Separator fits SMT assembly and electronics manufacturing workflows. You can use it to depanel all kinds of V-scored multi-connected PCB panels.

• Consumer electronics circuit boards
• Automotive electronic PCBA boards
• LED lighting aluminum substrate boards
• Communication equipment circuit boards
• Smart home electronic boards
• Industrial control circuit boards

Whether you run mass production or small-batch custom processing, this PCB depaneling machine meets your high-precision separation requirements. It works well for electronics manufacturing factories, PCB processing plants and SMT workshops for standard PCB depaneling tasks.

Why Choose Our Pneumatic Guillotine PCB Separator

We manufacture SMT automation equipment, and our Pneumatic Guillotine PCB Separator follows international standards. When you pick this guillotine type PCB separator, you gain these benefits:

Consistent cutting accuracy & long service life High-precision linear blades and thick rigid frame reduce downtime. You will not face frequent blade replacement or unexpected machine breakdowns during mass production.

Low-stress cutting to reduce your defect rate Our guillotine cutting technology prevents board deformation, solder joint drop-off and micro cracks. It helps you raise finished product yield and cut waste cost.

Flexible pure pneumatic design for your workshop The pneumatic power system adapts to different factory environments. It consumes less energy and creates no pollution to meet your workshop compliance requirements.

Easy operation & lower maintenance cost Compared with alternative PCB panel separators, this machine is simple to operate and maintain, delivering better overall cost performance. We support parameter customization to match your unique production line.

Full technical support before and after purchase Our team helps you solve all PCB depaneling challenges and optimize your production efficiency.

Ready to Upgrade Your Production Line?

If you are looking for reliable equipment for V-cut PCB panel singulation, our Pneumatic Guillotine PCB Separator with 2 linear guillotine type blades is an excellent choice.
It delivers high efficiency, precise low-stress cutting and safe operation. It improves your PCB separation quality, boosts throughput and lowers defective rates in your electronics manufacturing process.
Widely adopted by electronics manufacturers globally, this PCB depaneling machine comes with strict quality control and full after-sales support. We provide dependable SMT depaneling equipment and one-stop solutions for your production line.
