Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer

Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer
Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer

Large Image :  Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer

Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE
Model Number: HS-HC250S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package
Delivery Time: 7~9 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Product Name: PCB Buffer Warranty: 1 Year
Control: Touch Screen PLC: MITSUBISHI
Relay Brand: Schneider Optoelectronic Switch: OMRON
Material: Aluminum Alloy Condition: New
Thickness: 0.6-4.0mm Signal: SMEMA
Application: Electronic Assembly Color: Silver
Control System: PLC OEM/ODM: Available
Power Consumption: 200W Power Supply: AC220V
Air Pressure: 4-6bar Speed: 200-300pcs/min
Type: Automatic Weight: 220/240KG



Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer



​Technical Details

Transport height 910±20mm
Transportation direction L~R, or R~L
Board cycle time Approx 20 seconds
Magazine change over time Approx 30seconds
Track fixed side Front side
Operation side Front side
PCB thickness Min 0.6mm
Pitch selection 1-4(10mm pitch)
Power supply 220V,50/60Hz,±10%
Power 0.05kW
Air pressure 4-6Bar
Air consumption Max 10L/min
Number of magazines Upper:1 magazine, Bottom side:1 magazines
Signal SMEMA
Options 1, Touch screen control mode.
2, Automatic width adjustment.
3, Magazines quantity up to customer requirement.



Specification

Model HS-HC250S HS-HC330M HS-HC390L HS-HC460XL
Efficient PCB length 50*50~350*250mm 50*50~455*330mm 50*50~530*390mm 50*50~530*460mm
Magazine size 355*320*563mm 460*400*563 535*460*570mm 535*530*570mm
Machine dimension 1250*1200*1600mm 1460*1360*1600mm 1610*1480*1600mm 1610*1620*1600mm
Weight 170kg 230kg 300kg 330kg



Features

1. Use friendly soft touch LED membrane control panel.

2. FIFO,LIFO,Loader, Unloader,Reject mode selected.

3. Fast, smooth and precise indexing.

4. Pneumatic clamps provided for magazine alignment.

5. Pneumatic pusher’s pressure regulated.

6. Threshold’s system provided.

7. Additional magazines buffering capacity available upon request.

8. SMEMA compatible.



Machine drawing

Front Operation SMT Line Intelligent SMT Production Line Automatic PCB Buffer 0

Application

This unit is used as a buffer between SMD machine and Inspection equipment
