Automatic Soldering Robot with Remote Assistant for Inline THT/DIP AOI Before Wave Soldering

Brand Name:	HSTECH
Model Number:	AIS300
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Inline THT DIP AOI After Wave Soldering

Warranty:

1 Year

Control:

Touch Screen

PLC:

MITSUBISHI

Relay Brand:

Schneider

Optoelectronic Switch:

OMRON

Material:

Aluminum Alloy

Condition:

New

Thickness:

0.3 - 5mm

Signal:

SMEMA

Application:

Electronic Assembly

Color:

Silver

Control System:

PLC

OEM/ODM:

Available

Total Power:

2600W

Power Supply:

AC220V

Air Pressure:

4-6bar

Mounting Accuracy:

±0.01mm

Type:

Automatic

Weight:

30KG

Packaging Details:

Wooden package

Supply Ability:

100 sets per month

Product Description

Quick Installation Fast Inspection Speed Remote Assistant Inline THT DIP AOI Before Wave Soldering

Specification

Model	AIS300	AIS301
PCB Size	50x50mm~430x380mm	50x50mm~350x350mm
Thickness	0.3~7.0mm
Warping extent	<4mm
Component height	Top 150mm, bottom 25mm
Camera	5MP,color,CCD
Light source	RGB
FOV	45*37mm
Resolution	20um
Inspection
Mounting components defect	Missing,rolling,offset,damage,skew,redundant,dirty.
Solder defect	Excess,insufficient,bridge,no foot,missing solder,non-wetting.
Other function	Bar-code,QR cod,OCR
Speed	0.23sec/fov	0.25sec/fov
Software/Hardware
Operation system	Ubuntu 14.04 LTD 64bit
Function	Remote control, Gerber file importing, training tool for new models
Industrial PC	CPU intel i5,Independent Graphics Card,12G DDR,256SSD
Display	22 inch FHD LCD
Motion	High accuracy linear actuator
Power supply	AC220V,1KW
Air pressure	>0.5Mpa
Dimension(LHW)	110016301350mm	110012801300mm
Net Weight	800kg	700kg

Features

A, Core algorithm—— Convolutional Neural Network Algorithm

Application and Innovation in industry

Human-like inspection

Better compatibility

Training algorithm model of super large sample set

High generalization

Super detection ability, lower false positive

Supporting user self-training model

B, High wear resistance

C, Large inspection area and high compatibility

D, High inspection rate and low false positive rate.

E, Marble base, more stable.

F, Dual XY linear actuators, high speed, high accuracy
