Customized PCB Handling Equipment for Various PCB Sizes and Directional Requirements

Brand Name:	HSTECH
Model Number:	HS-460-CY
MOQ:	3 sets
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram, D/P
Supply Ability:	500 pcs per month

Detail Information

Place of Origin:

China

Certification:

Product Name:

SMT Conveyor

Other Name:

Link Conveyor

Color:

Blue,Grey,white

Transport Belt:

ESD Flat Belt

Belt Thickness:

1.0 Mm

Voltage:

1P AC 110V/220V 50/60HZ

Warranty:

1 Year

Packing:

Wrap, Wooden Box

Packaging Details:

Wooden box

Supply Ability:

500 pcs per month

Highlight:

Product Description

Stable Stainless Steel Manual Hand Crank Width Adjustable PCB Transporting Conveyor

Features

Constructed with a robust stainless steel frame for maximum stability and durability.
Featuring a hand crank for convenient width adjustment, allowing for precise customization.
Equipped with a durable black transport belt measuring 1.0mm in thickness, ensuring smooth and efficient movement of materials.
Utilizing aluminum alloy transport rails for added strength and smooth operation.
Incorporating LED button controls for intuitive operation and a speed adjustment motor for precise control over conveyor speed.
Optional features available, such as tower lights, inspection equipment, dust covers, and more, to tailor the machine to your specific needs.
Offering customized requirements to suit your unique application or process.
Available in lengths of 600mm, 1000mm, 1500mm, or custom lengths to fit your workspace or production line.
Equipped with SMEMA signal compatibility for seamless inline connection with other automation equipment.

Specification

Model		HS-C600/HS-C1000
Power Supply		AC220V or AC110V 50/60Hz
PCB Size		5050~500390mm
Width adjustment		Hand crank
PCB Direction		Left to right or right to left
Transmission Height		900 ± 20 mm
Transmission Speed		0.5-20 meters per minute adjustable
Track fixed side		front side fixed( or back side fixed for option)
Machine Length		0.5M/0.6M/0.8M/1M/1.5M
Options		Light,Fan,Magnnifying,Cover,Inspection
