Intelligent LED Bulb Glue Dispensing Machine with Four Work Stations for Versatile Applications

Intelligent LED Bulb Glue Dispensing Machine with Four Work Stations for Versatile Applications

Brand Name: HSTECH
Model Number: HS-D441
MOQ: 1 set
Price: Negotiable
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 sets per month
Detail Information
Place of Origin:
China
Certification:
CE
Product Name:
LED Bulb Glue Dispenser
Warranty:
1 Year
Control:
Touch Screen
Optoelectronic Switch:
OMRON
Material:
Aluminum Alloy
Condition:
New
Application:
Electronic Assembly
Control System:
PLC
Packaging Details:
Wooden package
Supply Ability:
100 sets per month
Highlight:

Intelligent LED Bulb Glue Dispensing Machine

,

Versatile Applications Glue Dispensing Machine

,

Four Work Stations Glue Dispensing Machine

Product Description

High-Capacity LED Bulb Glue Dispensing Machine with Four Work Stations



Introduce



The LED Bulb Glue Dispenser is a specialized automatic equipment designed primarily to mix two types of glue (Group A and Group B) in precise ratios and accurately apply them onto the surface of the workpiece. This machine has a broad range of applications in various industries, such as electronics manufacturing, home appliances, automotive, and beyond, for bonding, sealing, and filling processes.





Feature
The LED Bulb Glue Dispenser showcases advanced features and capabilities specifically engineered for efficient and precise glue dispensing. Below are the key highlights of its design and functionality:



High-Efficiency Production:

The dispenser excels with a seamless four-workstation cycle, capable of handling 1000 to 1500 pieces per hour, significantly boosting throughput and productivity.

Smart Workpiece Detection:

Incorporating an advanced detection system, the machine intelligently applies glue only when a workpiece is present, optimizing material usage and minimizing waste.

Customizable Gluing Patterns:

The dispenser provides flexible gluing tracks, including full circles, single points, segmented arcs, and other bespoke patterns tailored to individual workpiece requirements. This adaptability enhances its suitability for various manufacturing contexts.

Adaptable Working Modes:

Configurable in either four-station or two-station mode, the dispenser offers the versatility to accommodate different production needs and workpiece types.

User-Intuitive Interface:

With a user-friendly touch screen interface complemented by physical buttons, the dispenser is easy to learn and operate. Unique settings can be programmed for different glue types, optimizing performance according to each material's characteristics. This facilitates setup and enhances operational efficiency.



Precise Proportion Mixing:
The dispenser features a finely tuned mixing system that guarantees components A and B are blended in the exact ratio specified, ensuring optimal glue performance.

Enhanced Automation:
The automatic dispensing system bolsters production efficiency by minimizing manual intervention and reducing labor intensity.

Versatile Dispensing Techniques:
Multiple dispensing methods, including dripping, spraying, and flowing, cater to diverse process needs.

User-Friendly Adjustment and Operation:
The intuitive interface facilitates easy adjustment of dispensing parameters like pressure, speed, and duration.

Advanced Intelligent Control:
Equipped with a PLC or computer control system, the dispenser offers real-time monitoring of the dispensing process, ensuring stability and reliability.


Application scenarios:

Electronic Manufacturing:
It is utilized for encapsulating, bonding components, and sealing circuit boards, thereby enhancing product durability and reliability.

Automotive Industry:
In the automotive sector, it is employed for window sealing and interior bonding, ensuring both the sealing integrity and aesthetic appeal of vehicles.

Home Appliance Industry:
Within the home appliance industry, it plays a crucial role in assembling and repairing various appliances, offering robust connections and sealing solutions.

Crafts and Furniture:
For woodworking and handicraft production, it efficiently applies boiled cast glue, fulfilling the needs of craftsmen and furniture makers.


Specification

Model HS-BD4
MCU Industrial PLC
Programming Text Demonstration Programmer
Drive mode Precise Stepping Motor
Max Dispensing Diameter 160mm(two station),110mm(four station)
Motor Speed 0 ~ 300 RPM
Positioning Accuracy ±0.1mm
Z-axis Adjust Range 250mm
Z-axis Working Travel 50mm
Dimension (L*W*H) 420mm*532mm*532mm
Weight 35Kg
Working Power AC220V/50~60Hz/200W
Working Air Pressure 0.4~ 0.6Mpa(no condensation)
Working Temperature and Humidity Temperature: 0~40℃,Humidity: 20~90%





Application


The LED bulb and Par light glue dispenser has been tailored for meticulous glue application to secure lighting components. The Four-station Round Glue Dispenser stands out with its unique design of four stations on a rotating disc, positioned at 90-degree intervals. Every 90-degree turn of the revolution motor smoothly transfers the workpiece to the next gluing nozzle, maintaining a seamless operational flow.

During the glue application process, an auto-rotation motor rotates the workpiece uniformly, ensuring a consistent coating. This effective combination leads to a precise and streamlined gluing process, ideal for lighting manufacturers aiming to improve production quality and throughput.
