Panasonic PLC Control By Pass Function PCB Destacker Smart Button Control For SMT Line

This fully automatic PCB Destacker is a professional SMT inline board handling equipment designed for automatic separation and feeding of stacked bare PCBs. Adopting mature Panasonic PLC control system and smart button operation panel, this automatic PCB destacker features stable running, simple operation and strong compatibility. Equipped with practical By-Pass function, the machine supports flexible production switching, effectively solving board stacking, manual feeding instability and low line efficiency problems in SMT production. Widely compatible with different sizes and thicknesses of bare circuit boards, it can seamlessly connect with upstream and downstream SMT equipment to realize fully automated PCB unstacking, feeding and transmission, greatly improving the overall automation level of the production line.

This machine is used to loading the bare PCBs to the start of SMT line.

• Panasonic PLC control.
• Touch Screen Control, Step motor.
• Full sheet metal structure,cooling soldering, computer white surface.
• Uninterrupted loading, available for By-pass function.
• Fast PCB feeding time, around 6 sec.
• Smooth and parallel width adjustment(hand lead screw control).
• Three color tower light display.
• Whole machine in time error detection.
• SMEMA communication interface,standard 4 pin wire.

• SMT Line Feeding: Automatically loads bare PCBs from stacked configurations into the solder paste printer and pick-and-place machines, eliminating manual loading bottlenecks.
• Automated Unloading/Stacking: Collects finished PCBA boards at the end of the reflow oven or AOI inspection station, stacking them neatly into magazines to prevent oxidation.
• Pass-Through Buffering: Acts as an intelligent buffer conveyor to smoothly transfer boards between mismatched equipment speeds without interrupting the production flow.
• High-Mix Manufacturing: Easily accommodates frequent changeovers with quick, manual width adjustments and programmable logic for various PCB sizes.
• Smart Factory Integration: Connects via SMEMA or PLC protocols to central MES systems for real-time production monitoring and traceability.

1. Optimized Labor Costs: Automates repetitive board handling, reducing manual staffing requirements by up to 70% and minimizing human-induced defects.
2. Superior Yield Protection: Advanced separation mechanisms and ESD-compliant materials drastically reduce the risk of scratches, bends, and electrostatic damage to sensitive boards.
3. Global Standard Compliance: Designed with universal voltage support, metric sizing, and international safety standards, ensuring plug-and-play compatibility in any manufacturing facility worldwide.
4. Low Maintenance & High Reliability: Modular design with high-strength materials ensures minimal wear, low maintenance costs, and maximum uptime.
5. Comprehensive Support: Backed by detailed English operation manuals, video tutorials, and responsive remote technical support to ensure rapid deployment and troubleshooting.

Stop relying on manual board handling and start maximizing your production throughput. Contact us today for a customized quotation, CAD layout assistance, or to request a live video demonstration of the PCB Destacker in action. Our engineering team is ready to tailor a solution to your exact SMT line requirements.
