Bare PCB push up stacker board loader for SMT assembly line PCB magazine feeding

Fully automatic industrial bare PCB board loader push up stacker machine for SMT assembly line stacked bare PCB magazine loading feeding and material supplying process

Product Introduction

This automatic PCB stacker, also known as push up stacker and bare PCB board loader, is a professional automatic PCB handling equipment designed for standard SMT assembly lines. It integrates automatic PCB loading, stacking, feeding and material supplying functions, perfectly solving manual PCB placement confusion, low efficiency and board damage problems in electronic production processes.

Adopting mature PLC intelligent control system and anti-static structural design, this SMT PCB stacker supports stable and continuous feeding and stacking of bare PCBs and finished circuit boards. It can operate independently or be seamlessly connected with upstream and downstream SMT production equipment, realizing fully automated unmanned operation of PCB loading and stacking links. As a core piece of SMT assembly line equipment, it effectively improves the overall automation level and production consistency of electronic manufacturing lines.

Specification

Features

• Panasonic PLC control.
• Touch Screen Control, Step motor.
• Full sheet metal structure,cooling soldering, computer white surface.
• Uninterrupted loading, available for By-pass function.
• Fast PCB feeding time, around 6 sec.
• Smooth and parallel width adjustment(hand lead screw control).
• Three color tower light display.
• Whole machine in time error detection.
• SMEMA communication interface,standard 4 pin wire.

Versatile Application Scenarios

This automatic PCB stacker is a versatile solution tailored for diverse manufacturing environments:

• SMT Assembly Lines: Automating the stacking of bare boards or finished PCBs to streamline the transition between printing, placement, and reflow processes.
• LED Production: Capable of handling customized, longer PCB boards specifically required for LED strip and lighting manufacturing.
• Smart Factory Integration: Serving as a critical node in automated material handling systems, connecting seamlessly with PCB magazine loaders, unloaders, and conveyors to create a fully automated, lights-out production environment.

Why Choose Our PCB Stacker?

We understand that in industrial manufacturing, reliability and precision are non-negotiable. Our PCB stacker is built with a strong, firm, and stable design that prevents shifting during high-speed operations. By focusing on smooth stepper motor translation and minimizing conveyor clearances, we deliver a machine that not only meets but exceeds the demands of modern SMT production. Backed by comprehensive technical support and a commitment to quality, our equipment is designed to reduce your operational costs and boost your overall equipment effectiveness (OEE).

Ready to Optimize Your SMT Line?

Don't let manual board handling bottleneck your production. Upgrade to automated efficiency today. Contact us now for a customized quotation, detailed CAD drawings, or to schedule a virtual factory tour. Let our engineering team design the perfect material handling solution for your specific SMT manufacturing needs.
