Offline AOI Automatic Optical Inspection Machine For SMT And DIP Electronic Assembly Production Lines

Advanced offline PCBA visual inspection equipment designed for SMT and DIP electronic assembly production lines, replacing traditional manual inspection with automated optical technology.

This AOI machine utilizes modern optical imaging and professional image-analysis algorithms to capture high-definition PCB images and automatically identify component and solder-joint defects. It significantly improves quality control efficiency compared to manual inspection methods.

Supports inspection after SMT paste printing, reflow soldering, and DIP wave soldering processes. Ideal for multi-variant, small-to-medium batch electronics manufacturing with stable performance and easy maintenance.

High-speed industrial CCD cameras capture real-time PCBA images. Multi-dimensional algorithms analyze and compare these images against standard reference samples. The system automatically detects defects, marks positions, stores snapshots, and generates comprehensive inspection reports.

• Reliable Automation: 99%+ detection rate eliminates human-factor interference and reduces long-term production costs
• Multi-Process Compatibility: Single machine handles both SMT and DIP assembly inspection requirements
• Advanced Software Suite: CAD data import, offline programming, OCR recognition, SPC statistics, and comprehensive reporting capabilities
• Precision Mechanical Structure: High-rigidity base with precision lead-screws and linear guides ensures stable repeat accuracy
• Premium Components: Servo drive system, OMRON electrical parts, and long-life RGB LED lighting for reliable operation

• Excess solder and insufficient solder
• Solder voids and short-circuit bridges
• Non-protruding pins and other solder-joint failures

• Missing, shifted, wrong, or reversed components
• Tombstoned, damaged, or contaminated components
• Cold solder, insufficient/excess solder, bridging, and open-circuit issues

• Color extraction and statistical analysis
• OCR character recognition and color-distance analysis
• IC bridging short-circuit detection
• Black-white ratio and brightness analysis
• Shape-similarity analysis and CAD data import
• SPC process statistics and operator permission management
• Barcode scanning and multi-panel inspection
• Multi-machine networking and custom component libraries
• Daily/weekly/monthly report export
• Connection to multiple repair stations

Consumer electronics, industrial control boards, power modules, communication equipment, automotive electronics, medical devices, and other manufacturers with SMT & DIP soldering quality-control requirements. Particularly suitable for production lines with frequent product change-overs and mixed small-batch orders.

• On-site machine installation, commissioning, and operator training provided
• 12-month full-unit warranty effective upon machine receipt
• All non-human factor failures repaired free-of-charge during warranty
• Continued technical support and spare parts availability after warranty
• Remote online troubleshooting to minimize production downtime
