5 Modes Stepping Motor CCD Color Align System Mobil Phone BGA Rework Station with High Accuracy

Brand Name:	HSTECH
Model Number:	HS-700
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Mobile Phone BGA Rework Station

Warranty:

1 Year

Control:

Touch Screen

PLC:

MITSUBISHI

Relay Brand:

Schneider

Optoelectronic Switch:

OMRON

Material:

Aluminum Alloy

Condition:

New

Thickness:

0.3 - 5mm

Signal:

SMEMA

Application:

Electronic Assembly

Color:

Silver

Control System:

PLC

OEM/ODM:

Available

Total Power:

2600W

Power Supply:

AC220V

Air Pressure:

4-6bar

Mounting Accuracy:

±0.01mm

Type:

Automatic

Weight:

30KG

Packaging Details:

Wooden package

Supply Ability:

100 sets per month

Product Description

5 Modes Stepping Motor CCD Color Align System Mobil Phone BGA Rework Station

Specification

Mobile Phone BGA Rework Station	Model:HS-700
Power Supply	AC 100V / 220V±10% 50/60Hz
Total power	2600W
Heater power	Top heater 1200W(Max), bottom heater 1200W(Max)
Electric material	Driving motor + smart temp. controller + color touch screen
Temperature control	high precision K-sensor+ closed loop control + independent temp.controller (the precision can reach ±1℃)
Sensor	1pcs
Locating way	V shape PCB support + external universal fixture + laser light for centering and positioning
Overall dimension	L450mmW470mmH670mm
PCB size	Max 140mm160mm Min 5mm5mm
BGA size	Max 50mm50mm Min 1mm1mm
Applicable PCB thickness	0.3 - 5mm
Mounting accuracy	±0.01mm
Weight of machine	30KG
Mount chip weight	150g
Working modes	Five: Semi-auto/Manual/Remove/Mount/Weld
Usage Repair	chips / phone motherboard etc

Features

1.BGA optical alignment, fast, accurate.
2. Import drive motor, PLC intelligent temperature controller, true color touch screen, external high-definition large screen.
3.Temperature control: K type thermocouple closed-loop control, independent temperature control precision can reach ±1 ℃.
4.Positioning: V-slot, PCB bracket can be X, Y adjustment and configuration universal fixture.
5.Easy and convenient to operate.
6.Application to all models of mobile phones.cell phone repair station iphone ic replace machine
