Solder Paste Machine for High Precision PCB Printing with Fast Cycle Time and Easy Operation

Brand Name:	GKG
Model Number:	GSE
MOQ:	1 set
Price:	Negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	100 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,TUV,ROHS

Product Name:

Automatic Stencil Printer

Other Name:

Solder Paste Printing Machine

PCB Size:

50x50~400x340mm

Transport Height:

900±40mm

PCB Thickness:

0.4~6mm

I/Ov Interface:

SMEMA

Packaging Details:

Wooden Package

Supply Ability:

100 sets per month

Product Description

Solder Paste Machine for High Precision PCB Printing with Fast Cycle Time and Easy Operation

Whole Machine Specification

Repeat Position Accuracy	±0.01mm
Printing Accuracy	±0.025mm
Cycle Time	＜8 Sec
Product Changeover	old:<3 mins,new:<5 mins
Air supply	4~6 kgf/cm
Power supply	AC:220±10%,50/60HZ, 2.5KW
Control method	PC
Operation system	Windows XP/Win7
Machine Dimensions	1158(L) x 1362(W) x 1463 (H)mm
Machine Weight	Approx: around 1000Kg

Features

1, GKG special adjustment jacking platform. Stable and easy to adjust, it can quicklyadjust the pin jacking height of PCB with different thickness.

2, Cleaning system: GKG cleaning system equipped with three cleaning methods: dry cleaning, wet cleaning, vacuum. which can be combined

to use. It can also be cleaned by manual if customer do not need to use automatic cleaning to reduce the cleaning time and improve production efficiency. The newly wiping system ensures full contact with the stencil, increased vacuum suction can effectively eliminate the remaining paste

in the mesh, which can achieve effective automatic cleaning function.CCD part and c leaning system is separated, when CCD working, CCD part

independently move to reduce the servo motor load and improve the machine speed and accuracy.

3, Image and optical system. Using uniform ring light and high brightness coaxial light, with promise brightness adjustment function, then all types of Mark points can be well recognized (Including the rugged mark points), applicable for tin plating, coppering, gold plating,tin spraying, FPC and other types PCB with of different colors. With GKG patent mathematical model,able to ensure high accuracy.

4, High adaptability steel mesh frame clamping system. Able to print all kinds of size screen frames, and quickly change modular

production line.

5, Using Windows XP/win7 operation interface, with good man-machine dialogue function, and easy for operator quickly familiar with the operation especially when doing navigation effect of programming file. easy to switch Chinese/English interface, with operation log, fault record / fault self-diagnosis / fault analysis prompt / light alarm and other functions.

6, 2D paste printing quality test and analysis, Able to inspect shift ,insufficient paste, missing and bridge and other defects to ensure the printing quality.
