Intorduction

An NG/OK Unloader is a type of automated machinery used in the electronics manufacturing process, particularly in the inspection and sorting of printed circuit boards (PCBs) after assembly. The terms "NG" and "OK" refer to "No Good" and "Okay" respectively, indicating whether a PCB has passed or failed inspection

Features

1, PLC programing control.

2, Using friendly ‘soft touch’ LED membrane control panel

3, Selectable pitch setting.

4, Toggle level clamps provided for magazine alignment.

5, Pneumatic pusher’s pressure regulated.

6, High throughput with short magazine change-over time.

7, Collect NG/OK board from AOI, automatic store the NG/OK boards.

8, Standard SMEMA communication interface.

Specification


Applications

PCB Assembly Lines:
Commonly used in electronic manufacturing lines to separate defective PCBs from those that meet quality standards.
Quality Control:
Helps maintain high standards of quality by ensuring that only functional PCBs proceed to the next stage of production or packaging.
Rework Stations:
Defective PCBs can be routed to rework stations for repairs, ensuring efficient handling of non-conforming products.

Benefits

Increased Efficiency:
Automation reduces the need for manual sorting, speeding up the overall production process and minimizing labor costs.
Improved Quality Assurance:
Ensures that only properly functioning PCBs reach the final stages of production, enhancing product reliability and reducing returns.
Reduced Risk of Human Error:
Automated sorting minimizes the chances of errors associated with manual inspection and handling.
Data Tracking:
Many NG/OK unloaders can log data on inspection results, providing valuable insights for quality control and process improvement.
Space Optimization:
Compact designs enable efficient use of floor space in manufacturing facilities, allowing for better workflow management.
