Soft Touch LED Control PCB Buffer Machine Using Servo Motor With FIFO And By-Pass Function

Soft Touch LED Control PCB Buffer Machine Using Servo Motor With FIFO And By-Pass Function

Introduce

PCB Buffer Machine is an automated equipment used in the electronic manufacturing process to manage and control the flow and buffering of Printed Circuit Board (PCB) on the production line.

The main function of the PCB buffer machine is to balance and control the flow of PCBs between different workstations to ensure efficient operation of the production line. It is usually located at key locations on the production line, such as before and after the placement machine, and is used to adjust and balance the incoming and outgoing speed of PCBs to adapt to the work rhythm between different workstations.

The working principle of PCB buffer machine is generally as follows:

1.PCB entry: PCBs enter the buffer machine from the previous workstation, usually via a conveyor belt or conveyor system that guides the PCBs to the buffer area.

2.Buffer: In the buffer area, PCBs are arranged and maintained at a certain spacing and order. These buffers can be physical compartments, conveyor belts, or other forms of mechanical structures used to separate and store PCBs.

3.Control: The PCB buffer machine is equipped with a corresponding control system that can monitor and control the flow of PCB. It can adjust the incoming and outgoing speed and sequence of PCBs according to the status and needs of the front and rear workstations to ensure balanced and continuous operation of the production line.

4.PCB export: When the PCB needs to enter the next workstation, the buffer machine will release the PCB from the buffer area according to the preset order and time, allowing it to enter the next workstation for subsequent processing or assembly.

Advantages of PCB buffers include:

1.Balance the production line: By controlling the flow and buffering of PCBs, PCB buffer machines can balance the work speed and rhythm between different workstations on the production line, avoiding production bottlenecks and blockages between workstations.

2.Improve efficiency: By optimizing the flow and buffering of PCBs, PCB buffer machines can minimize production line downtime and waiting time, thereby increasing production efficiency and throughput.

3.Reduce errors: PCB buffer machines can effectively manage and control the order and status of PCBs, reducing production problems and defects caused by PCB chaos or errors.

Features

1, With FIFO and By-pass function, or cutomized to multiple function.

2, Soft touch LED control panel.

3, Using servo motor for accuracy positioning.

4, Leadscrew for width adjustment, smooth and stable.

5, The whole machine is small volume, won't take much factory space.

6, SMEMA communication interface, can be connected with other automation equipment.

7, Three color LED display for machine status.
