30W SMD Chip Counter Digital LED Component Counter With Leak Detection Function

30W SMD Chip Counter Digital LED Component Counter With Leak Detection Function

Introduce

Multiple Magazine PCB Loader is a device for automatic loading, mainly used in the production and testing process of printed circuit boards (PCB).

Functional Overview:
PCB sheets can be automatically taken out from multiple independent PCB magazines and sent to subsequent production or testing equipment.
It can automatically switch PCB sheets in different trays according to production needs.
Equipped with an advanced visual positioning system to ensure accurate positioning and feeding of PCB sheets.
It can coordinate with other equipment on the production line such as placement machines, reflow ovens, etc.

Main feature:
Multiple independent PCB trays can be connected to improve production flexibility.
Use high-precision manipulators or robot arms to pick and place sheets.
Equipped with an advanced visual positioning system to ensure accurate sheet positioning.
Supports automatic switching of different types or sizes of PCB sheets.
Integrated safety protection devices, such as grating sensors, emergency stop switches, etc.
It can achieve good signal docking and synchronous control with other equipment in the production line.

Main component:
Manipulator or robotic arm: used to automatically grab and place PCB sheets.
Visual positioning system: including cameras, image processing algorithms, etc.
Tray switching mechanism: can automatically switch sheets in different trays.
Transmission mechanism: such as conveyor belts, rollers, etc., used for sheet material transportation.
Program control system: PLC or industrial computer to achieve fully automated control.
Safety protection devices: such as grating sensors, emergency stop switches, etc.

Application scenarios:
SMT production line: automatic loading during patch and reflow soldering processes.
Testing link: Automatic loading and positioning in front of the testing equipment.
Sample production: Automatically switch and load PCB sheets of different specifications.
Small batch production: Improve production efficiency and reduce the burden of manual operations.

Features

1. Stainless steel machine body.

2. Leak detection function, when tracking missing components, the counter will stop and reminder you.

3. The operation is simple, the positive and negative can be counted, and the function is really preset.
4. The quantity of preset parts can be used for the design of SMT belt type parts.
5. It can be equipped with scanning gun and bar code printer for easy management.
6. Counting speed can be ajustable,improve the efficiency,meet the different size tape.
7. The counter use drafting LCD screen. Small size, light weight, easy to carry
8 .Use patent reflector,humanized operation platform.
9. Fully control the components in the factory, avoid mistakes.

10. Fully control the number of SMT parts in the factory, and avoid the inventory and capital accumulation. Small size, light weight, easy to carry.

Specification

About Packaging
