Touch Screen Control Dual Head Suction Screw Feeder Auto Screw Locking Machine

Touch Screen Control Dual Head Suction Screw Feeder Auto Screw Locking Machine

Brand Name:	HSTECH
Model Number:	HS-DH6331
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Screw Locking Machine

Feeding:

Suction Feeding

Axis:

6 Axis

Screws Compatible:

M1-M6, Or Customized

Moving Range:

500*300*300*100mm

Material:

Main Aluminum

Port:

Shenzhen

Oem:

Yes

Packaging Details:

Wooden package, foam inside

Supply Ability:

100pcs per month

Product Description

Touch Screen Control Dual Head Suction Screw Feeder Auto Screw Locking Machine

Introduction

The screw machine is a dual screw driver, dual platform, and suction screw feeder automatic screw locking machine, it use touch scrren and manual moving the screw head to do the location, its a much easy programming type, save much programming time.

Its a new type screw locking machine which can replace the traditional manual teaching pandent programming machine, it's widely used in the electronics industry.

Compatible for screws from M1 to M6, other special screws, also can be customization.

Specification

Model	HS-DH6331
Production name	Automatic Screw Locking Machine
Moving range(X/Y1/Y2/Z)	600300300100100mm
X/Y1/Y2 axis moving speed	Closed loop motor :1-800mm/s
Z axis moving speed	Closed loop motor: 1-300mm/s
X/Y1/Y2 axis max load	Closed loop motor: 5KG
Z axis max load	Closed loop motor: 3KG
Power supply	AC110V/220V, 50/60Hz
Repeat accuracy	±0.02mm
Document support	CAD CorelDraw
Suitable screws	M1-M6
Machine dimension8	880585800mm
Machine weight	120kg

Main parts brand

1, Motor: Shinano

2, Guide: Hiwin

3, Photoelectric switch: Omron

4, Power supply: Meanwell

Features

1.Suction feeding with single feeder & locking head.
2.Desktop-friendly, connects to auto production lines.
3.6-axis operation, 600x300x300x100x100mm moving range.
4.Supports multiple screw bins in suction mode.
5.Double workstation boosts efficiency, cuts labor costs.
6.Quickly adapts to M1-M6 screws with screw guider change (customizable).
7.Easy to operate, allows concurrent machine control.
8.Stores hundreds of files, each with 1000 screw bit capacity for easy recall.

About Product

About Details

Touch Screen Control Dual Head Suction Screw Feeder Auto Screw Locking Machine 2

About Packaging
