Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom

Brand Name:	HSTECH
Model Number:	HS-DS400
MOQ:	1 set
Price:	Negotiable
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

PCB Destacker

Other Name:

Bare Board Loader

Power Supply:

AC110V/220V,single Phase

Program:

PLC

PLC Brand:

Mitsubishi

Air Pressure:

0.6Mpa

PCB Thickness:

0.6~4.0mm

Warranty:

1 Year

Packaging Details:

Wooden package,with foam

Supply Ability:

100 sets per month

Product Description

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom

Features

1.PLC control
2.LED pushbutton easy control
3.SMEMA signal connection
4.Manual PCB thickness adjustment
5.Manual PCB width adjustment
6.LED display status
7.Aluminum structure, anti-displacement
8.Straight-through mode
9. Change line 10 seconds
10.Uninterrupted loading
11.Anti-static conveyor belt
12. Self-programming error display, code + maintenance instructions

Application

The machine is dedicated to the efficient automatic loading of bare circuit boards onto SMT lines and supports stacked loading for fast and continuous supply of circuit boards.

Specification

Function	Used for loading bare PCB to smt line after received down-stream machine signal.
Transport height	910±30mm
Transportation direction	L~R, or R~L
Operation	Front operation
Track fixed side	Front side
PCB thickness	0.6~4.0mm
PCB components height	±35mm
PCB feeding time	Approx. 10 seconds or Specify
Board weight	≤3KG
Power supply	220V,50/60Hz,±10%
Power	0.05kW
Air pressure	0.6Mpa
Air consumption	<20L/min
Signal	SMEMA

Model	HS-DS400	HS-DS530
Efficient PCB length	50~400mm	50~530mm
Transport PCB width	50~400mm	50~500mm
PCB thickness	Min 0.6mm	Min 1.0mm
Machine dimension	5037701200mm	6009201200mm
Weight	110kg	130kg

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom 0

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom 2

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom 3

Omron Relay SMT Line PCB Loader with Self Programmed Error Display and Heavy Bottom 4

About Packaging

About Us

Shenzhen Hansome Technology Co., Ltd(HSTECH), initially focused on PCB processing equipment, and later expanded to PCB depaneling machine and SMT cleaning machine. The company has a professional R & D team and experienced marketing team, follow the market trend, continuous innovation, to provide cost-effective products, help customers to reduce costs and improve efficiency.
